We Promise Excellence in Every Aspect.
Still Hesitant? See What You're Really Investing In.
Real Success Stories: High ROI, Zero Learning Curve
MetalFab lets me make 1.000+ tiny lure parts in-house, no more spending €250K on outsourcing. A profitable game-changer!
Almost no learning curve, totally worth it. The cuts and welds are so clean they're nearly perfect, slashing my post-processing work.
Waiting on suppliers for jigs killed our workflow & budget. Now, we take prototypes from CAD to finish in-house, reducing time from weeks to hours.
With over 40 years in welding, this is by far the easiest welder I have ever used. Its speed and accuracy slash project times, reduce labor costs and boost my profits.
By bringing cutting in-house, I've slashed my costs by 35%. The camera lets me use every inch of my material and scrap. That one feature alone is enough to pay for the machine.
Flexible Ways to Invest in Your Growth
*Discounts cannot be stacked, please choose the biggest savings.
Why Settle? See How xTool MetalFab Outperform Others
Accessories and Consumables
Choose the necessary parts according to your needs and consuming frequency.
xTool Selected Air Compressor & Air Dryer
Generate air for CNC metal cutting (up to 4mm stainless steel
Double-layer Cutting Nozzle Set
Dross-free carbon steel cuts of 2mm and above (extra oxygen required.)
SaveGas Cutting Nozzle Set
1 set included in the CNC package with an estimated lifespan of 1 month.
Ordinary Cutting Nozzle
1pcs included in the CNC package with an estimated lifespan of 3 months.
Welding Nozzle Set
1 set included in the welder package with an estimated lifespan of 3 months.
Ordinary Protection Lens
10pcs included in the welder package with an estimated lifespan of 2 months.
In the Box
FAQ
xTool MetalFab can cut/stainless steel, aluminum, brass, carbon steel, galvanized sheet, titanium, nickel alloy, magnesium.
Welding and cutting capabilities:
- The 1200W welder can weld up to 5mm stainless steel/carbon steel, while the 800W model handles up to 4mm.
- The 1200W welder can cut (handheld cutting) up to 5mm stainless steel/carbon steel, while the 800W model handles up to 3mm.
- When paired with a CNC cutting platform:
Design differences:
- The 1200W welder includes a free wire feeder, while the 800W model has a built-in wire feeding mechanism and is lighter in weight.
Welding: Nitrogen or argon gas with purity above 99,99% is suitable for most metals. The required welding pressure ranges from 0,1–0,2 MPa, with a gas flow rate of 15–30 L/min (argon is required for welding titanium alloys).
Cutting: Compressed air, nitrogen/argon (purity >99,99%), or oxygen are commonly used as shielding gases.
- xTool air compressor and air dryer provide stable compressed air, enabling burr-free cuts at 0,6 MPa for 4mm stainless steel, 4mm aluminum, 3mm copper, 1mm carbon steel, and galvanized steel (1200W laser) when paired with xTool SaveGas™ Nozzle. This setup significantly reduces costs compared to gas cylinders.
- Nitrogen/argon (at 1,2 MPa) can achieve burr-free cuts for the same materials (1200W).
- Oxygen is primarily used for cutting carbon steel and galvanized steel above 1mm thick. With a dual-layer nozzle and focal extension tube at 0,06–0,07 MPa, it can cut up to 10mm carbon steel/galvanized steel (1200W).
Cleaning: Compressed air is sufficient, but nitrogen or argon is recommended for brighter, oxidation-free results.
Yes, xTool MetalFab supports engraving on stainless steel, galvanized steel, titanium, and coated metals (e.g., anodized aluminum). It supports vector engraving, vector filling, and bitmap filling. Just use XCS for one-click parameter setup!
Note: To protect the laser, avoid engraving on high-reflectivity metals like copper.
The camera-driven workflow will significantly enhance your metalwork efficiency and minimize material waste.
xTool MetalFab integrates dual high-definition cameras for intelligent metal processing-advantages that products without cameras cannot match:
The 16MP Panoramic camera captures full-bed imaging for precise positioning and enables Smart Nesting function with up to 98,7% material use. The close-range camera enables micron-level precision for secondary/fine processing through localized high-res imaging.
xTool MetalFab operates on the XCSSoftware, designed for intuitive control and streamlined workflows:
It features the Material EasySet Library with100+ pre-optimized parameters for 30+ materials. You only need to select the material you want to cut, and all parameters can be applied with a single click. It also supports Auto Lead-in Lines, Automatic Path Optimization, which significantly improves cutting efficiency.
We have designed xTool MetalFab to ensure a smooth and simple user experience, so you don’t need to worry about lacking experience—you can get started in just five minutes!
It features the 550g ultra-light integrated welding gun which enables a 5-second quick-release. The 8-Inch Smart Touchscreen has 108+ built-in parameters for one-click use.
xTool MetalFab can weld up to 5mm stainless steel or carbon steel, and we have passed SGS welding quality tests, so you can rest assured about its performance and reliability!
Yes, we are building a global localized service network, with established local service teams in the U.S. and Europe. You can access:
- 24/7 online support (via email, live chat, or phone).
- 1-on-1 dedicated warranty assistance.
- Demo room reservations for in-person machine testing and material trials.
You can access the after-sales policy, shipping policy, warranty policy via the link.
The xTool MetalFab laser welder can operate with a voltage of 200-240V, running at full power with approximately 4200W. The maximum current is 21A. It is recommended that users connect it to an independent circuit rated at 220V-21A or higher.
For the US, we provide a NEMA6-50p or NEMA6-30p plug. For other regions, we provide power cables, and an electrician is required to install the appropriate circuit.
Customer Reviews
I have been impressed with the xTool brand since I purchased my first xTool D1 Pro several years ago. From packaging and shipping to customer service, they excel. I have cut and welded mild steel, stainless steel and aluminum with it. Cutting on the CNC is a breeze and handheld cutting is amazing when dealing with clean materials. There are nuances to laser welding that make it different from other types of welding. Unlike MIG welding you must be conscious of where you are pointing the gun. The demos all show someone welding a butt T joint aimed at the inside corner of a joint. That is easy but doing outside corners or any weld where you can shoot past the target is like using a rifle. You must not shoot things that you don't want burned or cut. The rust cleaning function is pretty cool however it leaves small markings on the material being cleaned. At least that's what I have seen after cleaning using the CNC. I do not regret my purchase of the Metalfab 1200W and CNC enclosure.
Very impressed with the quality of machine. Easy to set up and have so many uses definitely happy with my purchase and excited to see how many new projects I can now make more efficiently.
excellent customer service, cant wait to give the new machine a spin when it gets delivered
I am impressed with the CNC aspects. I have been proceeding slowly but the results ate good. My prior experience with the p2 has helped me get up to speed on the software.
The instructions for assembly and setup are very good.
It cuts very well so far.
